Part Number | Revision | Document Title and Content Summary |
|---|---|---|
10100-00063 | N | Product Information, Compliance, and Safety |
10410-00317 | W | Operation Manual (OM). The OM contains: • Basic setup information and configuration • Front and rear panel control and connector identification • Initial checkout procedure • VNA instructional primer |
10410-00318 | AH | Calibration and Measurement Guide (MG). The MG describes: • Calibration theory and methodology along with descriptions of calibration kits, verification kits, and verification software. • Measurement approaches and methods. • Both 2-Port and 4-Port operations are described. |
10410-00328 | C | ME7838A-3744A Rx Noise Figure Measurement Guide • Millimeter-wave noise figure measurement approach. |
10410-00319 | AE | User Interface Reference Manual (UIRM). The UIRM provides: • Descriptions of every menu and dialog box in the UI. • Suggestions for typical procedures such as calibration or markers. • The instrument context-sensitive help is derived from the UIRM content. |
10410-00322 | AE | Programming Manual (PM). The PM contains the following: • VNA programming introduction • Command descriptions for IEEE, system, troubleshooting, and SCPI commands. • Programming examples with LabView, LabWindows, VISA/C#, and Legacy Drivers. |
10410-00323 | F | Programming Manual Supplement (PMS). The PMS contains the following: • Anritsu 37xxxX Lightning Supported and Non-Supported Commands • HP8510 Supported Commands • System limit parameters |
